How to Use the Dashboard to Track Supply Chain Health KPIs

Overview

The Chainsaw overview dashboard provides a real-time view of your organization’s supply chain health. It surfaces key performance indicators (KPIs), violation trends, and activity patterns that help you assess risk posture, measure policy effectiveness, and communicate supply chain health to stakeholders.

Prerequisites

• Any role in Chainsaw (Member or above)
• Traffic flowing through the proxy

Step 1: Navigate to the Dashboard

Click Overview in the sidebar (or it loads by default after login). The dashboard shows several sections of metrics and charts.

Step 2: Understand the KPI Cards

The top of the dashboard shows key metric cards:

Blocked Packages

The total number of package requests blocked by policies in the selected time range. A high number may indicate active threats or overly aggressive policies.

Cache Hit Ratio

The percentage of package requests served from Chainsaw’s local cache versus fetched from upstream. A high ratio means faster builds and less reliance on external registries.

Compliance Score

An aggregate measure of how well your package consumption aligns with your policies. This reflects the percentage of packages passing all policy checks.

Active Exceptions

The number of currently active exceptions (packages explicitly allowed despite policy violations). A growing number may indicate policy debt.

Step 3: Use Time Range Filters

Adjust the time range to analyze different periods:

All KPI cards and charts update dynamically when you change the time range.

Step 4: Filter by Repository and Client

Narrow the dashboard view to specific contexts:

Repository Filter

Select a specific repository to see metrics for just that ecosystem:

Client Filter

Select a specific client to see activity for a particular team or pipeline:

Step 5: Read the Violation Charts

Violations by Severity

A breakdown showing violations categorized as critical, high, medium, and low:

Violation Trends

A time-series chart showing how violations change over time. Look for:

• Spikes — May indicate a new attack or a newly deployed policy
• Declining trends — Your policies are working and teams are upgrading
• Steady high numbers — May need policy tuning or developer education

Step 6: Explore Additional Metrics

Vulnerability Breakdown

See the distribution of vulnerabilities by CVSS/EPSS severity across your supply chain:

License Coverage

Track the ratio of packages with known vs unknown licenses:

Top Exceptions

See which packages have the most active exceptions — these represent your highest accepted-risk items:

Real-Time Event Feed

A live feed of package requests and their outcomes:

Patch Priority Widget

The Patch Priority Widget ranks the upgrades that retire the most known-exploited and high-EPSS risk per merge. The list is built by walking each direct dependency’s transitive closure (default depth 5) and combining KEV-pinned, EPSS ≥ 0.5, and “+N deps unblocked” badges into a single ordered queue.

Click any row to drop into the simulator and preview exactly which CVEs clear and which transitives unblock — see How to Run the Patch Simulator.

Monitor-to-Enforce Nudge

When you have policies running in monitor mode that have collected enough samples to be promoted to block without breaking the build, a banner appears at the top of the overview prompting the upgrade.

The banner only fires when:

• The policy has been in monitor for at least the configured observation window (default 14 days).
• The fire rate is non-zero (the policy is actually catching things).
• The rate of monitor-fires that were later granted exceptions is below the no-noise threshold.

This keeps you from sitting on a working policy in monitor mode forever, which is the most common cause of the “we have Chainsaw but nothing is enforced” pattern.

Step 7: Build Stakeholder Reports

Use the dashboard for different audiences:

For Security Leadership

Focus on:

• Compliance score trend
• Critical/high severity violations
• Exception growth rate
• Overall trust score distribution

For Engineering Leadership

Focus on:

• Cache hit ratio (build speed)
• Blocked package impact (developer friction)
• Top violations by team (who needs help)

For Compliance Auditors

Focus on:

• Time-range filtered metrics for the audit period
• Violation counts by category
• Exception documentation
• Pair with SBOM and audit log exports

Dashboard Monitoring Cadence

Next Steps

• How to Monitor Violations and Respond to Blocked Packages — Deep dive into violation handling
• How to Export Your SBOM in CycloneDX Format — Generate compliance artifacts
• How to Use Audit Logs to Track Consumption — Complement dashboard with audit trails
• How to Use Billy to Investigate and Draft Policies — Ask Billy about what the dashboard shows
